Throne

Throne SRPNT

Throne SRPNT

$4,499.00 USD
$4,499.00 USD
Sale Sold out

Low stock



Discover the culmination of two years of intensive research, design, and hard work with the all-new SRPNT eDIRT BIKE by Throne Cycles! Harness the electrifying power of 72 volts and 10,000 watts, all encased in a custom alloy frame forged under 3000 lbs. of pressure for unparalleled strength. With two integrated kill switches and strategically placed lights, the SRPNT eDIRT BIKE prioritizes safety while delivering unmatched performance and excitement on rugged terrain and off-road trails. Experience a new level of thrill and be one of the first to own this cutting-edge bike. However, please note that as exhilarating as it may be, the SRPNT eDIRT BIKE is not street-legal. Prepare to elevate your off-road adventures with the SRPNT eDIRT BIKE.



MOTOR
Motor Type: PMSM
Mounting Position: Mid
Weight / Motor External Diameter: 9.55kg / 155mm
Motor Axial Length: 130mm
Peak Efficiency: 98%
Cooling Method: Air-Cooled
CONTROLLER
Controller Type: FOC
Dimensions: 160mm x 142mm x 79mm
Peak Efficiency: 98.50%
Power Modes: Eco, High, and Sport
MOTOR POWER SYSTEM
Rated Voltage: 72V (DC)
Rated Torque / Peak Torque: 95115Nm
Motor Shaft Output Torque @ 1000RPM: 460Nm
Rated Rotation Speed: 5400rpm
Peak Efficiency: 97%
Range of Efficiency (≥80): 3Nm - 45Nm
TRANSMISSION
Gear Ratio: 13:51
Transmission: Motorcycle Chain & 428 Drive Chain
Model: German Continental Brand, 8M CXA
ELECTRICAL COMPONENTS
Horn: CQC
Battery: 72V 40AH Lithium Battery with 176 LG Cells
Battery Life Time: 500 Cycles
Battery Charge Level: Integrated Battery LCD Display
Charger: 9A
Charging Time: 3.5 Hours
USB Connection: Type C
Speedometer: TFT
LED Headlight & Rear Light: Yes
FRAME DETAILS
Chassis - Swing Arm Material: No.6061 T4&T6 Aluminum
Chassis Construction Method: Forged by 3000 Tons of Pressure
Chassis Surface & Color Processing: Baked Paint
Front Suspension: Inverted Suspension Fork with 200mm Travel
Rear Shock Absorber: KKE Suspension Link System
Wheel Type & Size: Front/Rear :1.4-19 , 1.6-19 Alloy Hubs
DIMENSIONS
Ground Clearance: 270mm
Wheelbase:  1250mm
Seat Height: 85cm
Vehicle Dimensions: 1880mmX805x1130mm
DRIVE
Top Speed:  90km/h
Net Weight 73kg
Rear Sprocket 51T
Side Stand Yes with Kill Switch
Battery Usage  600 Uses
Carry Capacity  320lb
