Ultra Oil Pump Kit

○Approx. 3 times the discharge volume (compared to a 6V vehicle)
○Concave Drive Shaft

*
*After installing the oil pump kit, be sure to check the oil pressure rise.
*Major modification of the orifice is required for installation.(Super oil pump Φ1.5, Ultra oil pump Φ2.0)
*Installation requires a separate crankcase gasket (part number: 966-1015004) and a clutch outer cover gasket suitable for use with each vehicle are required.
*CHALY 50 (FNO.CF50-3000031-) / CHALY 70 (FNO.CF70-3000029-) cannot be installed with Super Oil Pump.However, it is possible to install the Ultra Oil Pump Kit by using the stock flat type oil pump cover..

The oil discharge amount is more than twice as much with the super oil pump and more than three times as much with the ultra oil pump only by replacing the stock oil pump (1.8 times as much as the stock oil pump for 6V vehicles and 12V vehicles).This prevents the decrease of cooling function by the engine tuning such as big bore, and the decrease of oil pressure by the installation of the oil cooler, etc., and brings out the tuned engine performance to the maximum.

Points of Attention

* If there may be an instruction manual included, it will be written in Japanese.
